THERMSHIELD™ 1231C

Working temperature from -40°C to +650°C

Exhaust temperature up to +750°C

Excellent thermal insulation

Aesthetic appearance, customizable design

Space-saving installation

Good formability for installation

FUNCTION:

Stacks Image 6847
Open all Close all
  • Product Description
    ThermShield™ 1231C is a tubular insulation cover designed for exhaust pipes.

    ThermShield 1231C outer layer is aluminum foil bellows while the inner layer is high silicon non-woven or glass fiber non-woven material. Holes or slots can be opened according to customer requirements, and it is recommended to install and fix by clamping.

    The corrugated aluminum foil tube of Thermshield 1231C has considerable hardness and good formability. It is easy to install and provides excellent abrasion and impact resistance in actual use.
  • Typical Applications

    • Exhaust Pipe/EGR

  • Datasheet Downloads
  • Construction and Typical Product Characteristics
    Outer Layer: High-temperature resistant corrugated aluminum foil tube

    Inner Layer: Hi-silica or glass fiber non-woven fabric
  • Specifications & Dimensions
    ThermShield 1231C requires customization for specific applications.
  • Product Testing

    Performance Data - ThermShield™ 1231C

    For optimal viewing experience on a mobile device, rotate to a landscape orientation.

    Property
    Test Method
    Result
    Working Temperature
    Up to +750°C
    Thermal Durability
    240 hours at +750°C (inlet temperature)
    No cracking or delamination
    Flammability
    SAE J369
    Self-extinguishing
    Low Temperature
    BH 100-016
    No cracking or delamination
    Fluid Resistance
    BH100-003
    No cracking or delamination

    All numeric performance data shows average or typical values. Please consult your sales representative for product drawings, test reports and OEM approvals.
