FASTWRAP® 2305

Operating temperature up to +150°C (+302°F)

Excellent abrasion resistance

Flexible and conformable

Very easy installation

Integrated closure system

FUNCTIONS:

Stacks Image 8083
Open all Close all
  • Product Description
    FastWrap® 2305 is an open sleeve designed to offer a high level of component protection. Constructed with a combination of monofilament and multifilament yarns, FastWrap 2305 also incorporates an adhesive tape system to ensure secure closure of the sleeve.

    The adhesive closure system is divided into two parts to ensure both location and closure. One adhesive strip helps hold the sleeve in place on the application while the second strip creates the secure closure. Installation is repeatable and optimizes material usage.

    FastWrap 2305 is flexible, conformable, and adaptable to many diameters. The integral closure system enables to product to remain closed even when flexed or curved during routing. Easy to install, even on large lengths, FastWrap 2305 can reduce installation costs and the product is delivered in the flat form to provide the additional benefit of reduce transportation costs.
  • Typical Applications

    • Wire Harnesses
    • Vent Hoses
    • TOC Hoses
    • Brake and Shift Cables

  • Datasheet Downloads
  • Construction and Typical Product Characteristics
    Warp Yarn: Polyester (PET) Multifilament
    Fill Yarn: Polyester (PET) Multifilament
    Adhesive System: Acrylic Adhesive
  • Sizes / Availability

    Standard Sizes

    Nominal Size
    Recommended Application Range
    mm
    Min Ø
    Max Ø
    30
    21
    30
    40
    31
    40


    Availability
    FastWrap™ 2305 is available in nominal sizes 30mm and 40mm and cut to your specification. Recommended cut lengths are in 5mm increments. Please see regional drawings for cut length tolerances.

    Standard color is black. Please consult your sales representative for regional packaging details and standards.
  • Product Testing

    Performance Data – FlexFit® 2115

    For optimal viewing experience on a mobile device, rotate to a landscape orientation.

    Property
    Test Method
    Result
    Temperature Rating
    240 hours at +175°C (+150°C rating)
    Pass +150°C (+302°F)
    Low Temperature Flexibility
    SAE J2192
    Pass -40°C (-40°F)
    Flammability
    FMVSS 302
    Pass
    Melt Temperature
    ASTM D3418
    +245°C to +265°C (+473°F to +509°F)
    All numeric performance data shows average or typical values. Please consult your sales representative for product drawings, test reports and OEM approvals.
