REFLEXWRAP™ 1466

Operating temperature up to +200°C (+392°F)

Self-closing tubular design

Excellent radiant heat protection

Fluid and chemical resistant

Easy to apply

Flexible

FUNCTIONS:

Stacks Image 6847
Open all Close all
  • Product Description
    ReflexWrap™ 1466 is a self-wrapping, reflective sleeve designed to provide thermal protection from both radiant and convective heat. Composed of a woven fiberglass base fabric and a lamination of aluminum foil, the product can withstand convective heat soaks and simultaneously protect critical components from radiant or reflected heat.

    The unique woven structure imparts a level of flexibility not found in other reflective products. It also allows the product to maintain a circular profile when flexed.

    The self-wrapping design of ReflexWrap™ 1466 allows for quick and easy installation while the addition of a self-sealing adhesive reinforcement allows for permanent closure. The adhesive strip acts as a barrier to dirt and fluids while maintaining the full integrity of the finished aluminized sleeve.
  • Typical Applications

    • Engine harnesses
    • Tubing and cables

  • Datasheet Downloads
  • Construction and Typical Product Characteristics
    Outer Layer: Aluminum

    Inner Layer: Warp Yarn: Fiberglass multifilament; Fill Yarn: Polyphenylene sulfide (PPS) monofilament
  • Product Testing

    Performance Data – ReflexWrap™ 1466

    For optimal viewing experience on a mobile device, rotate to a landscape orientation.

    Property
    Test Method
    Result
    Operating Temperature
    -40°C to +200°C (-40°F to +392°F)
    Heat Aging: 3000hrs at +200°C
    240hrs at +250°C
    ISO 6722
    No visible damage, no cracks, no delamination
    Maintains its properties
    Flammability
    FMVSS 302
    D45 1333
    Pass
    Self extinguishing Type B
    Thermal Effectiveness
    SAE J2302
    See graph below
    Fluid Resistance
    D47 1924
    No visible degradation or alteration after being exposed to the following test cycles:

    • Immersion for 15s at 23°C, followed by a drying period of:
      • 24h at 150°C: motor oil, automatic transmission fluid, manual transmission oil.
      • 24h at 23°C: zinc chloride, brake fluid.

    • Immersion for 48h at 70°C, followed by a drying period of:
      • 24h at 23°C: Urea of clean up Ad blue.

    • In vapour for 2h at 70°C, followed by a drying period of 4h at 23°C: battery fluid.

    • Vaporization, 10 times, each vaporization followed by a drying period of 27min:
      • At 40°C for gazole, unloaded petrol 98, Std fuel C + 15% methanol, E85 bio ethanol.
      • At 70°C for windscreen washer.
    All numeric performance data shows average or typical values. Please consult your sales representative for product drawings, test reports and OEM approvals.
