PROTEXX-SHIELD® 7040 / 7045
High level of thermal insulation +700°C / +1292°F
No burn through in torch exposure of +1000°C (1832°F) x 30 minutes
Withstands multiple cycles of blast exposure
Flexible and easy to install
Customized designs for custom fit
Compatible to directly adhere to battery case
FUNCTIONS:
-
Product DescriptionProtexx-Shield® 7040 / 7045 is a high performing flexible thermal and flame barrier specifically designed as anti-propagation protection for extreme conditions within EV battery pack. Product is a highly engineered composite structure that provides multiple functions. These functions include providing flame barrier, blast barrier, high level of thermal insulation and electrical insulation. Protexx-Shield 7045 is available with pressure sensitive adhesive to allow for direct application onto a variety of surfaces.
Protexx-Shield 7040 is constructed of multiple layers of materials to provide a high level of thermal insulation and survive harsh thermal runaway environments. The outer material layer is a proprietary silicone-based coating applied to a silica fabric structure providing flame and blast protection. The next material layer is a textile insulation that reduces temperature transfer. Entire structure is designed to help limit thermal runaway propagation and any associated failure modes.
Protexx-Shield 7045 takes the base of Protexx-Shield 7040 and applies a pressure sensitive adhesive to the insulation layer for direct mounting functionality. -
Typical Applications
• Limit propagation of thermal runaway
• EV Battery Case Liner
• EV Battery Pack:
– Module level protection
– Component level protection -
Datasheet Downloads
-
Support DocumentationWatch our video showcasing benchmark testing at temperatures exceeding 1500°C to compare the performance of Protexx-Shield and Mica in extreme conditions.
The results are in, and they're groundbreaking! -
Sizes / Availability
This product is designed to customer specific application, geometry and performance requirements. Due to the nature of this custom product, please consult your local sales representative for more details.
-
Installation Tools
There are no installation guides available at this time. Please contact your sales representative or distribution team for further support.
-
Product Testing
Performance Data – Protexx-Shield® 7040 / 7045
For optimal viewing experience on a mobile device, rotate to a landscape orientation.
PropertyTest MethodResultThermal RunawaySP Internal Test MethodResists 30min x +1000°C Torch, No burn throughThermal Insulation exposed to +1000°C (+1832°F) torchSP Internal Test MethodBackside plate less than +250°C in +1000°C TorchThicknessASTM D17773mmFlammabilityUL 94V0 RatingThermal ConductivityASTM D15030.046 [W/m.k]DensityASTM D1777; D3776; D3776M0.47 g/cm3Blast ResistanceUL 2596 TaG TestGreater than 2 cyclesSpecific HeatASTM C17841.1 [J/g*K]All numeric performance data shows average or typical values. Please consult your sales representative for product drawings, test reports and OEM approvals.
