QUIETWRAP™ 3009

Operating temperature up to +100°C (+212°F)

Wrappable acoustic sleeve

High level of mechanical protection

Flexibility prevents exposure of wires

Excellent noise suppression

Easy to install

Extremely lightweight

Excellent tape compatibility

FUNCTIONS:

Stacks Image 8083
Open all Close all
  • Product Description
    QuietWrap™ 3009 is a wrappable protective sleeve designed to provide excellent noise suppression and abrasion resistance. Composed of a non-woven polyester and durable woven substrate, the product is lightweight and its thickness provides superior noise suppression performance for rattling/rubbing noise caused by vibrations.

    QuietWrap 3009 has excellent flexibility that facilitates harness workability and routing while keeping wires from being exposed. The product also has great weatherability, enabling it to be applied to areas in wetting risk such as door harnesses.

    QuietWrap 3009’s unique design allows for quick and easy bundling of wire and cable assemblies. Compared to multiple component solutions such as vinyl tube and urethane foam, QuietWrap 3009 provides a single product solution that reduces complexity and installation time. QuietWrap 3009 delivers premium performance level for multiple functions of acoustic management and mechanical protection.
  • Typical Applications

    • Door harnesses
    • Instrument panel harnesses
    • Seat harnesses
    • Roof harnesses
    • Tailgate harnesses

  • Datasheet Downloads
  • Construction and Typical Product Characteristics
    Outer Layer: Polyester (PET) non-woven

    Inner Layer: Polyester (PET) woven sleeve
  • Sizes / Availability

    Standard Sizes

    Commercial Part Number
    Nominal Diameter
    (mm)
    Recommended Application
    Range (mm)
    Min Ø
    Max Ø
    QuietWrap 3009 5
    5
    1
    5
    QuietWrap 3009 8
    8
    5
    8
    QuietWrap 3009 10
    10
    8
    10
    QuietWrap 3009 13
    13
    10
    13
    QuietWrap 3009 16
    16
    13
    16
    QuietWrap 3009 19
    19
    16
    19
    QuietWrap 3009 25
    25
    19
    25
    * Max diameter is defined as a nominal 90° sleeve overwrap. A variety of application-based variables will dictate the appropriate sleeve size for use on each harness. Proper sleeve sizing is at the discretion of the end user.

    A reduced overlap could be acceptable in certain applications allowing for a larger max diameter harness. Please consult your local sales representative for recommendations and guidance.
  • Product Testing

    Performance Data – QuietWrap™ 3009

    For optimal viewing experience on a mobile device, rotate to a landscape orientation.

    Property
    Test Method
    Result
    Temperature Rating
    240 hours at +125°C (+100°C rating)
    Pass +100°C (+212°F)
    Low Temperature Flexibility
    SAE J2192
    Pass -40°C (-40°F)
    Flammability
    SAE J369
    Self-extinguishing
    Acoustic Performance
    LV 312
    E Class
    All numeric performance data shows average or typical values. Please consult your sales representative for product drawings, test reports and OEM approvals.
