REFLEXWRAP™ 1463LF

Operating temperature up to +200°C (+392°F)

Excellent radiant and convective heat protection

Designed for reduced fiber pollution and optimized fray resistance

Self-wrapping design allows for break-outs

Lightweight, flexible & easy to install

Fluid and chemical resistant

FUNCTIONS:

Stacks Image 6847
Open all Close all
  • Product Description
    ReflexWrap™ 1463LF is a self-wrapping, reflective sleeve designed to provide thermal protection for both radiant and convective heat applications. Composed of an aluminum foil laminated to a fiberglass woven fabric, the product protects critical components from radiant or reflected heat while withstanding convective heat soaks up to +200°C (+392°F).

    The unique design provides excellent cut quality resulting in improved fray resistance and reduced fiber pollution. The self-wrapping construction and integrated closure tape allows for quick and easy installation. The adhesive closure acts as a barrier to dirt and fluids while maintaining full reflective coverage. Finally, the flexible structure allows the product to maintain a circular profile when flexed.
  • Typical Applications

    • Quick Connectors
    • Brake Lines
    • Fuel Lines
    • Cable assemblies
    • Engine Harnesses

  • Datasheet Downloads
  • Construction and Typical Product Characteristics
    Outer Layer: Aluminum

    Inner Layer: Warp Yarn — Fiberglass multifilament; Fill Yarn — Polyester (PET) monofilament
  • Sizes / Availability

    Product Specifications

    Nominal Diameter
    Recommended Application Range* mm (in)
    Min Ø
    Max Ø
    6

    1

    6
    8

    6

    8
    10

    8

    10
    13

    10

    13
    16

    13

    16
    19

    16

    19
    22

    19

    22
    25

    22

    25
    32

    25

    32
    38

    32

    38

    *Max diameter is defined as having a 100° - 110° overwrap depending on nominal diameter. A variety of application-based variables will dictate the appropriate sleeve size for use on each harness. Proper sizing is at the discretion of the end user.

    A reduced overlap could be acceptable in certain applications allowing for a larger max diameter harness. Please consult your local sales representative for recommendations and guidance.

  • Installation Guide / Tools
  • Product Testing

    Performance Data – ReflexWrap™ 1463LF

    For optimal viewing experience on a mobile device, rotate to a landscape orientation.

    Property
    Test Method
    Result
    Temperature Rating
    240 hours at +250°C
    3000 hours at +200°C
    -40°C to +200°C (-40°F to +392°F)
    No visible damage, cracks or delamination
    Thermal Endurance
    25mm above a 538°C (1000°F) heat source for 6 hours
    Pass
    No degradation or delamination
    Low Temperature Flexibility
    SAE J2192
    Pass -40°C (-40°F)
    Flammability
    SAE J369
    FMVSS302
    Self extinguishing
    Self extinguishing
    Fluid Resistance
    SAE J2192
    Pass
    Tensile Strength - Warp
    ASTM D5035
    Warp: 250 lbf/in. min.
    All numeric performance data shows average or typical values. Please consult your sales representative for product drawings, test reports and OEM approvals.
