FYREJACKET® 1610

Operating temperature up to +260°C (+500°F)

Superior flame retardance

Excellent thermal protection

Flexible

Water tight and fluid resistant

Non-flammable

FUNCTION:

Stacks Image 6847
Open all Close all
  • Product Description
    FyreJacket® 1610 is a thickwall braided fiberglass sleeve coated with silicone rubber that provides thermal protection. FyreJacket 1610 is used to protect hoses, lines and cables in high temperature areas. It additionally provides protection against short-term hazards such as flame blasts. When burn-through is a threat, the specially designed sleeve construction retards the penetration of the flame. This can allow critical components to continue to function for a short amount of time.

    In addition to protecting assemblies and components from high temperatures and flame, FyreJacket 1610 can be used to insulate lines and cables. This type of insulation protects external components from heat while often increasing the efficiency of the internal components.

    The braided construction of FyreJacket 1610 allows excellent flexibility in temperatures as low as -60°C (-76°F). The silicone coating is highly resistant to a wide range of solvents and fluids.
  • Typical Applications

    • Heater hoses
    • Power steering hoses
    • Fuel lines
    • Brake lines

  • Datasheet Downloads
  • Support Documentation

    There are no support documents available at this time. Please contact your sales representative or distribution team for further support.

  • Sizes / Availability

    Standard Sizes

    Commercial Part Number
    Nominal Diameter (mm)
    FyreJacket 1610 8

    8
    FyreJacket 1610 10

    10
    FyreJacket 1610 13

    13
    FyreJacket 1610 16

    16
    FyreJacket 1610 19

    19
    FyreJacket 1610 22

    22
    FyreJacket 1610 25

    25
    FyreJacket 1610 32

    32
    FyreJacket 1610 38

    38
    FyreJacket 1610 45

    45
    FyreJacket 1610 51

    51
    FyreJacket 1610 57

    57
    FyreJacket 1610 64

    64
    FyreJacket 1610 76

    76
    FyreJacket 1610 89

    89
    FyreJacket 1610 101

    101
  • Installation Tools

    There are no installation guides available at this time. Please contact your sales representative or distribution team for further support.

  • Product Testing

    Performance Data – FyreJacket® 1610

    For optimal viewing experience on a mobile device, rotate to a landscape orientation.

    Property
    Test Method
    Result
    Temperature Rating
    240 hours at +285°C (+260°C rating)
    Pass +260ºC (+500°F)
    Low Temperature Flexibility
    SAE J2192
    Pass -60°C (-76°F)
    Flammability
    SAE J369
    Self-extinguishing
    Fluid Resistance
    SAE J2192
    Pass
    All numeric performance data shows average or typical values. Please consult your sales representative for product drawings, test reports and OEM approvals.
