REFLECTSHIELD® 1440P

Operating temperature up to +175°C (+347°F)

Narrow profile

Highly efficient thermal insulating substrate

Can be self-adhered directly to component

Die-cut material

Low tooling costs

Short lead times

Eases installation

Outstanding dissipation of surface temperature

Available with various attachment methods

FUNCTIONS:

Stacks Image 8169
Open all Close all
  • Product Description
    ReflectShield® 1440P iis a three-layer composite system designed to provide excellent protection for components that must survive in high temperature areas. Aluminum is used as the outer layer for reflectance of radiant heat while the second inner layer utilizes polyester for insulation. The third layer can be a pressure sensitive adhesive (PSA) or a second layer of aluminum. The resulting product can then be slit to width and length or die cut into complex geometric shapes.

    Use of a pressure sensitive adhesive allows the product to be adhered directly onto a component, which reduces both tooling costs and lead times. If mechanical attachment methods are preferred, the PSA is replaced by the second layer of aluminum. Accessories such as clips can then be assembled to the product for attachment purposes.

    ReflectShield 1440P does an outstanding job or dissipating surface temperatures to protect components and its low profile allows the product to be used under carpet as well as in engine compartment and underbody applications.
  • Typical Applications

    • Under Carpet
    • Engine Compartment
    • Underbody
    • Plastic Component Protection

  • Datasheet Downloads
  • Construction and Typical Product Characteristics
    Outer Layer: Aluminum

    Middle Layer: Polyester (PET) non-woven

    Inner Layer: Pressure-sensitive adhesive (PSA) or Aluminum
  • Product Testing

    Performance Data – ReflectShield® 1440P

    For optimal viewing experience on a mobile device, rotate to a landscape orientation.

    Property
    Test Method
    Result
    Temperature Rating
    168 hours at +175°C (+347°C rating)
    No degradation
    Thermal Endurance
    BH100-503
    No degradation or delamination
    (25mm above a +538°C heat source for 6 hours)
    Low Temperature Resistance
    BH100-016C
    Pass -40°C (-40°F)
    Flammability
    SAE J369
    Self extinguishing
    Fluid Resistance
    BH100-003B
    Pass
    All numeric performance data shows average or typical values. Please consult your sales representative for product drawings, test reports and OEM approvals.
